Basic Information
Name
Model
Items Dimensions
Weight
Xiaomi Smart Projector L1 Pro
XMTYY03PFMG
210 × 128 × 189 mm
2.0 kg
Display
Display Technology
Brightness
Resolution
Throw Ratio
Screen Dimensions
Lens Focus
Keystone Correction
Auto Obstacle Avoidance
Auto Screen Alignment
Projection Method
LCD
400 ANSI Lumens
1920 × 1080P
1.21 : 1
40”～120"(Recommend: 60"-100")
Auto Focus
Auto Keystone Correction
Support
Support
Forward, Side, Hoisting(15°)
Hardware
Processor
Built-in Storage
MT9630 high-performance chip platform
2 GB DDR3/16 GB eMMC
System
System
Mirroring Display
Bluetooth
Wireless Connectivity
Android TV™ OS
Google Cast
Bluetooth 5.0
Wi-Fi IEEE 802.11 a/b/g/n/ac 2.4GHz/5GHz
Speaker & Audio
Audio Effects
Speaker
Dolby Audio
5W full-range × 2
Electrical
Rated power
Standby Power
Auto power off
Input
Noise
Storage Temperature/Humidity
Operating Temperature/Humidity
≤ 120.0 W
≤ 0.50W
Support
19.0 V ⎓ 6.32 A
≤ 30 dB(A) (Theater mode at an ambient temperature of 25°C)
-20℃ to 55℃ ≤ 90%RH
0℃ to 40℃ / 20%RH–80%RH
Basic
Projector*1
Power Adapter*1
Power Cable*1
User Manual
Warranty Notice
Desiccants
